H&H | DB Series Industrial Line

Call For A Quote

H&H | DB Series Industrial Line

MODEL:DB Series Industrial Line

GVWR:14000 lbs


LENGTH:12' - 16'



HITCH TYPE:bumper pull

Truly the best dump trailers on the market. Make sure to look at more then the price difference. You will appreciate what H&H is offering.

This trailer has a 83 inch interior width. 14 foot long box with 1 piece steel floor. 24 inch high 1 piece side walls. Side board provisions. Tandem 7,000 pound easy lube spring axles and 16 inch 10 ply radial tires on white steel modular wheels. Trickle chargers standard with all H & H 14 and 16 foot dumps. Full L E D light package with -40 degree rated wire harness. 2-5/16 posi lock adjustable height coupler. Media blasted frame with black powder coat paint. 2×12 inch electric drum brakes on both axles. 4 D-rings welded to the floor of the trailer. Pull out ramps standard on all 14 and 16 foot H and H dump trailers. Dual acting rear door. KTI hydraulic pump powered by Deka deep cycle battery in a lockable tool box. 6 inch cylinder on Champion scissor hoist. Available lengths are 12′ (6.14 cu/yd), 14′ (7.17 cu/yd), and 16′ (8.19 cu/yd). This trailer can be used for storm clean-up, construction, agriculture, and much more.

Models – H&H DB Series Commercial Grade Dump

  • DBW12′ 7T’ DBW Series Hydraulic Dump 14,000 GVWR
  • DBW14′ 7T’ DBW Series Hydraulic Dump 14,000 GVWR
  • DBW16′ 7T DBW Series Hydraulic Dump 14,000 GVWR
(2) Slipper Spring Straight Axles – EZ Lube Hubs
(4) 5/8″ D-Rings Inside Bed
D-Rings Inside Bed

Heavy duty anchor points used to secure your equipment to when hauling it.

10 Gauge Steel Floor
12″ Electric Brakes With Breakaway.
12v Deep Cycle Battery
12v Trickle Charger
2 5/16″ Adjustable Coupler
Adjustable Coupler 2 5/16

These couplers are height adjustable to allow you to level the trailer with the towing vehicle.

24″ Tall Formed Steel Walls
7000 Lb Dropleg Jack
8″ Hot Mill Channel Steel Frame
Barn Door Gate With Aggregate Spreader Function
ChampionTM Scissor Lift – 2-way 5×16 Cylinder
Dual Purpose Oversized Pump And Tool Box
Extra Thick Stake Pocket Tie-downs & Side Mounted D-rings
Full LED, DOT Compliant Lighting Includes Combination Stop, Turn, And Taillights.
Integrated Tarp Shroud
L.E.D Lights
Sealed Wiring Harness
Slide In Ramps For Dump
Loading Ramps for Dump Trailer

These ramps are stored in pockets at the rear of the trailer for easy use. Structural channel is used in order to provide a strong and durable ramp.

Spare Tire Carrier
ST235/80R16 (10) Ply Radial Tires
Standard Side Board Provisions
Steel Treadplate Formed Fenders
Wide 83” Interior Box Width
12,000lb Spring Loaded Dropleg Jack
12,000 lb Spring Loaded Drop Leg Jack

The Heavy Duty 12k spring loaded, jack saves you time and energy. When parking your trailer you simply pull the foot pin and press the jack foot to the ground, instead of having to crank to lower the jack foot. The spring loaded foot also quickly retracts to the up position to save even more time and energy.

7 Guage Steel Floor Upgrade
Crank Style Roll Tarp
Mesh Tarp Kit

By law, many municipalities require that dump trailers be outfitted with tarps. Our dump trailer tarp kit option helps ensure that your aggregate and/or cargo stays where it belongs until you decide otherwise. These trailer tarps are constructed of high-grade mesh and provides years of reliable use.

Rear Drop Down Loading Legs
Rub Rail Over Stake Pockets
A Wide Range Of Options Are Available To Add To Or Modify The Exterior & Interior Of These Trailers. For Enquires, Please Call Us And Our Sales Team Will Assist You With Available Options.


Some photos may show optional features. There are many options and features so please check with our staff as they will be happy to assist you.
